Electrophoresis Power Supply is a key component of the electrophoresis process, providing the electric current necessary to drive the separation of biomolecules (proteins, nucleic acids, etc.) through a gel.
Cat. No. :
YB-PSBrand :
YanbiotechProduct Origin :
ChinaSpec. :
ProgrammableProduct Introduction
Electrophoresis Power supply controls the voltage and current applied to the gel, which dictates how the molecules migrate through the gel matrix during electrophoresis.
Product Specifications
|
Product Name |
Programmable Electrophoresis Power Supply |
Dual Module Electrophoresis Power Supply |
|
Item Code |
YB-PS |
YB-PSD |
|
Channel |
Single channel, a total of 6 groups of output ports. |
Independent dual channels, a total of 6 groups of output ports. |
|
Terminal |
Output port parallel output. |
The left and right sets of independent dual power supply outputs can also be independently controlled without interfering with each other. |
|
Temperature |
4-40℃ |
4-35℃ |
|
Parameters |
600V,600mA,300W |
500V,500mA,250W |
|
Voltage Range |
6-600V |
6-500V |
|
Current Range |
6mA-600mA |
6mA-500mA |
|
Type |
Constant voltage, constant current, gradient voltage, gradient current |
Constant voltage, constant current, gradient voltage, gradient current |
|
Timing Range |
0-99h60min |
0-99h60min |
|
Pause/Resume Function |
Yes |
YES |
|
Programmable method |
Gradient Voltage, gradient current, three steps |
Gradient voltage, gradient current, three steps |
|
Power off memory function |
Yes |
YES |
|
Screen size |
4 inches |
4 inches |
|
Input power |
AC 180-240V/110-120V, 50/60HZ |
AC 180-240V/110-120V, 50/60HZ |
|
Size |
265*215*120mm |
265*215*120mm |
|
Net Weight |
1.8kg |
2.25kg |
Key Features
Programmable Function: can set four working modes: constant voltage, constant current, gradient voltage and gradient current;
Additional 2 sets of 12V outputs: can be used with blue light meters and dispensing lamps for independent control.
Many abnormal Notices: such as overvoltage, overcurrent, overload, variable load, no load, etc.
